COM-M Series Spherical Bearings

Product Features: Metal to Metal, Commercial Series, PTFE Optional, Inch&Metric Size Available Ball:52100 Bearing Steel,Precision Ground,Heat Treated, Hard Chrome Plated Race:Alloy Steel, Oil Coated,Zinc Plated Race Optional We are a Professional Manufacturer and Accept Special Request. Email Us [email protected] to Get a Latest Price or a Sample

Description

COM-M Series Spherical Bearings

BALL MATERIAL
52100 BEARING STEEL,PRECISION GROUND,HEAT TREATED
HARD CHROME PLATED
RACE MATERIAL
ALLOY STEEL
OIL COATED, ZINC PLATED RACE OPTIONAL

Product Features:
Thread:Right/Left
Regular Size: Male Size from CMR3M-CMR20M/Female Type from CFR3M-CFR20M
Inch Size and Metric Size Both Available
Custom Option:Material/Size

COM-M Series Spherical Bearings Size Chart

MALE ROD END
RH. MALE ROD END
LH. B D W T BALL AM N CM a° STATIC GRAMS
CMR3M CML3M 3 12.5 6 4.25 7.93 27 M3 X0.5 15 23 1775 7
CMR5M CML5M 5 16 8 5.75 11.1 33 M5X0.8 20 22 5168 12
CMR6M CML6M 6 19 9 6.25 12.7 36 M6X 1.0 22 23 7296 18
CMR8M CML8M 8 22.25 12 8 15.88 42 M8X 1.25 25 28 13591 31
CMR10M CML10M 10 27 14 9.5 19.05 48 M10X 1.5 29 26 21024 68
CMR10Mx1.25 CML10Mx1.25 10 27 14 9.5 19.05 48 M10X1.25 29 26 21024 68
CMR12M CML12M 12 30 16 10.75 22.23 54 M12 X 1.75 33 27 25819 78
CMR12Mx1.25 CML12Mx1.25 12 30 16 10.75 22.23 54 M12X1.25 33 27 25819 78
CMR12Mx1.5 CML12Mx1.5 12 30 16 10.75 22.23 54 M12X 1.5 33 27 25819 78
CMR14M CML14M 14 34.75 19 12.25 25.4 60 M14X2.0 36 30 35214 118
CMR16M CML16M 16 38 21 12.75 28.58 66 M16X2.0 40 33 37391 173
CMR16Mx1.5 CML16Mx1.5 16 38 21 12.75 28.58 66 M16X 1.5 40 33 37391 173
CMR18M CML18M 18 42 23 14.75 31.75 72 M18X 1.5 44 30 47903 260
CMR20M CML20M 20 46 25 16.25 34.93 78 M20X 1.5 47 29 57101 290
FEMALE ROD END
RH. FEMALE ROD END
LH. B D W T BALL AM N CM a° STATIC GRAMS
CFR3M CFL3M 3 12.5 6 4.25 7.93 21 M3 X0.5 10 23 5746 10
CFR5M CFL5M 5 16 8 5.75 11.1 27 M5X0.8 14 22 8247 18
CFR6M CFL6M 6 19 9 6.25 12.7 30 M6X 1.0 14 23 11895 25
CFR8M CFL8M 8 22.25 12 8 15.88 36 M8X 1.25 17 28 15190 40
CFR10M CFL10M 10 27 14 9.5 19.05 43 M10X 1.5 21 26 22750 80
CFR10Mx1.25 CFL10Mx1.25 10 27 14 9.5 19.05 43 M10X 1.25 21 26 22750 80
CFR12M CFL12M 12 30 16 10.75 22.23 50 M12 X 1.75 24 27 25819 95
CFR12Mx1.25 CFL12Mx1.25 12 30 16 10.75 22.23 50 M12 X 1.25 24 27 25819 95
CFR12Mx1.5 CFL12Mx1.5 12 30 16 10.75 22.23 50 M12 X 1.5 24 27 25819 95
CFR14M CFL14M 14 34.75 19 12.25 25.4 57 M14X2.0 27 30 35214 160
CFR16M CFL16M 16 38 21 12.75 28.58 64 M16X2.0 33 33 37391 215
CFR16Mx1.5 CFL16Mx1.5 16 38 21 12.75 28.58 64 M16X 1.5 33 33 37391 215
CFR18M CFL18M 18 42 23 14.75 31.75 71 M18X 1.5 36 30 47903 300
CFR20M CFL20M 20 46 25 16.25 34.93 77 M20X 1.5 40 29 57101 350

MALE ROD END RH.	MALE ROD END LH.	B	D	W	T	BALL	AM	N	CM	a°	STATIC	GRAMS
CMR3M	CML3M	3	12.5	6	4.25	7.93	27	M3 X0.5	15	23	1775	7
CMR5M	CML5M	5	16	8	5.75	11.1	33	M5X0.8	20	22	5168	12
CMR6M	CML6M	6	19	9	6.25	12.7	36	M6X 1.0	22	23	7296	18
CMR8M	CML8M	8	22.25	12	8	15.88	42	M8X 1.25	25	28	13591	31
CMR10M	CML10M	10	27	14	9.5	19.05	48	M10X 1.5	29	26	21024	68
CMR10Mx1.25	CML10Mx1.25	10	27	14	9.5	19.05	48	M10X1.25	29	26	21024	68
CMR12M	CML12M	12	30	16	10.75	22.23	54	M12 X 1.75	33	27	25819	78
CMR12Mx1.25	CML12Mx1.25	12	30	16	10.75	22.23	54	M12X1.25	33	27	25819	78
CMR12Mx1.5	CML12Mx1.5	12	30	16	10.75	22.23	54	M12X 1.5	33	27	25819	78
CMR14M	CML14M	14	34.75	19	12.25	25.4	60	M14X2.0	36	30	35214	118
CMR16M	CML16M	16	38	21	12.75	28.58	66	M16X2.0	40	33	37391	173
CMR16Mx1.5	CML16Mx1.5	16	38	21	12.75	28.58	66	M16X 1.5	40	33	37391	173
CMR18M	CML18M	18	42	23	14.75	31.75	72	M18X 1.5	44	30	47903	260
CMR20M	CML20M	20	46	25	16.25	34.93	78	M20X 1.5	47	29	57101	290

FEMALE ROD END RH.	FEMALE ROD END LH.	B	D	W	T	BALL	AM	N	CM	a°	STATIC	GRAMS
CFR3M	CFL3M	3	12.5	6	4.25	7.93	21	M3 X0.5	10	23	5746	10
CFR5M	CFL5M	5	16	8	5.75	11.1	27	M5X0.8	14	22	8247	18
CFR6M	CFL6M	6	19	9	6.25	12.7	30	M6X 1.0	14	23	11895	25
CFR8M	CFL8M	8	22.25	12	8	15.88	36	M8X 1.25	17	28	15190	40
CFR10M	CFL10M	10	27	14	9.5	19.05	43	M10X 1.5	21	26	22750	80
CFR10Mx1.25	CFL10Mx1.25	10	27	14	9.5	19.05	43	M10X 1.25	21	26	22750	80
CFR12M	CFL12M	12	30	16	10.75	22.23	50	M12 X 1.75	24	27	25819	95
CFR12Mx1.25	CFL12Mx1.25	12	30	16	10.75	22.23	50	M12 X 1.25	24	27	25819	95
CFR12Mx1.5	CFL12Mx1.5	12	30	16	10.75	22.23	50	M12 X 1.5	24	27	25819	95
CFR14M	CFL14M	14	34.75	19	12.25	25.4	57	M14X2.0	27	30	35214	160
CFR16M	CFL16M	16	38	21	12.75	28.58	64	M16X2.0	33	33	37391	215
CFR16Mx1.5	CFL16Mx1.5	16	38	21	12.75	28.58	64	M16X 1.5	33	33	37391	215
CFR18M	CFL18M	18	42	23	14.75	31.75	71	M18X 1.5	36	30	47903	300
CFR20M	CFL20M	20	46	25	16.25	34.93	77	M20X 1.5	40	29	57101	350

Custom Service Process:Select Similar Product — Confirm MOQ — Send Inquiry — Send your Drawings or Samples — Customization
Select product (If your product is not on our website, select a similar product) — Confirm the quantity you need meet up with our MOQ — Send inquiry with your Drawings or Samples — We will reply to you and confrim details — Send details to our factory and start customization
About Us:

Registration Name: Shanghai YongZhen Machine Components Co., Ltd.
Brand Name: SYZ
Established: 2002
Location: Shanghai,China
Business Type: Manufacturer
Main Products: Rod Ends, Rod Ends Kits, Spherical Bearings, Ball Joints, Linkage Adjuster, Rod Ends Related, Clevis and Yoke, Linkage Suspension, DOM Tubing, Custom Machining
Working Hours: 9:00 AM-18:00 PM Monday to Friday, China Beijing Time GMT+8
Know More About Us, Please Go To About Page or Contact Us.

Packing and Shipping:

Packing: Individual Plastic Bag, Thread with Protected Cover, Exported Carton
Delivery Time: Inventory Parts Shipped at Same Day; Production Usually 30-45 Days
Shipping Method: Air Freight by DHL/TNT /FEDEX Great Discount Rate in 3-7 Days; Headache-Free Ocean Freight with All Procedures Taken Care of to Doorstep in 30-40 Days
