LINKAGE ROD

LCR-122 Linkage Connecting Rod 25.25 in, 3/8-24 RH/LH Thread, 3/8 in Bores, Steel Race

Part No.: LCR-122  ·  Adjustable motion-transfer assembly series
✓ ISO 9001 Certified
✓ SGS Verified
✓ 26+ Years Factory
✓ OEM / ODM Ready
Thread: 3/8-24 RH/LH
Nominal Length: 25.25 in.
L1 Min / Max: 24.626–25.75 in.
A1 / A2: 0.375 / 0.375 in.
B1 / B2: 0.500 / 0.500 in.
W1 / W2: 0.406 / 0.406 in.
Weight
1.17 lbs
Material
Carbon steel; chromoly steel; aluminum alloy steel optional; stainless steel optional
Get a Quote →
Request Free Sample Back to Spec. Page
⚡ Typically responds within 24 hours
MOQ:50 pcs / model
Lead Time:7–15 days
Sample:Free (excl. freight)
Payment:T/T · PayPal · L/C
Overview

Linkage Connecting Rod Product Overview

LCR-122 is a 25.25 in linkage connecting rod for adjustable mechanical linkages, control rods, and motion-transfer assemblies. The assembly uses 3/8-24 RH/LH thread geometry with 3/8 in bore ends using steel race spherical rod-end bearings. Dimensional references are L1 24.626-25.75 in, L2 23.250 in reference, L3 2.75 in typical, A1/A2 0.375/0.375 in, B1/B2 0.500/0.500 in, S1/S2 1.625/1.625 in, and W1/W2 0.406/0.406 in. Material options are carbon steel, chromoly steel, aluminum alloy steel optional, and stainless steel optional. Confirm the final material, finish, thread hand, and hardware configuration with SYZ when requesting a quotation.

LCR-122 Linkage Connecting Rod 25.25 in, 3/8-24 RH/LH Thread, 3/8 in Bores, Steel Race dimensional product drawing
Size Chart

Linkage Connecting Rod Series — Full Size Range

All available sizes in the Linkage Connecting Rod series. Can’t find your size? Contact us for custom dimensions.

Part NumberWeight (lbs)ThreadNominal LengthL1 MinL1 MaxA1A2B1B2L2 (ref)L3 (typ)S1S2W1W2
