• Housing: 4130 heat treated chromoly steel, zinc plated (custom size, RH/LH available).
• Ball: 4130 chromoly steel, hard chrome plated.
• Bushing: Polyurethane or delrin.
Tell us the dimensional target, material preference, and application constraints. We'll help match or develop the right solution.
Ask for Custom SupportREBUILDABLE FLEX JOINT are articulated bushing-based joints for 4-link, radius-rod, trailing-link, control-arm, and other custom suspension assemblies. The housing, ball or sleeve, and polyurethane or polymer wear elements work together to provide movement while keeping the connection serviceable. Select mounting width, bolt size, bushing material, preload, travel, and maintenance approach for the actual shock, contamination, and duty-cycle conditions.
Rebuildable flex joints are designed for articulated suspension links where the joint must accommodate movement while remaining serviceable. Verify travel, mounting width, bolt size, and bushing preload in the complete link.
These joints are commonly integrated into fabricated control arms, radius rods, and trailing links on custom vehicles. Use appropriate spacers and bracket geometry to prevent binding through suspension travel.
The serviceable format can help teams and builders inspect or replace wear components without replacing the whole link. Set maintenance intervals according to contamination, shock, and duty-cycle conditions.
Suitable for performance suspension and competition hardware programs that need rebuildable joints with predictable service intervals.
Can be supplied for custom assemblies using threaded sleeves and alternate RH/LH thread requirements.
Works well in heavy-duty fabricated linkages where durable housings and replaceable internals help extend service life.
A rebuildable flex joint is used in suspension and articulated linkage assemblies where high-load movement and serviceable internals are required.
The housing uses heat treated 4130 chromoly steel with zinc plating, and the ball uses hard chrome plated 4130 chromoly steel.
This series uses polyurethane or Delrin bushings depending on the intended compliance, wear behavior, and application setup.
The threaded spanner nut design supports rebuildable service and controlled retention of the internal joint assembly on selected parts.
Mounting width, bolt diameter, thread size, thread length, housing O.D., and the internal bushing configuration are the key fitment points.
Yes. SYZ can review custom sizes and RH/LH thread requirements for OEM and fabrication programs.
