Description
3/4″(.750″) Commecial Spherical Bushings COM12T
| BALL MATERIAL | ||||
| 52100 BEARING STEEL, HEAT TREATED HRC58-64 | ||||
| HARD CHROME PLATED | ||||
| RACE MATERIAL | ||||
| ALLOY STEEL, OIL COATED | ||||
| LUBRICATION GROOVE AND HOLE IN O.D. OF RACE | ||||
| TEFLON LINER OPTIONAL, ADD “T” TO SUFFIX | ||||
COM Series Metal to Metal Alloy Steel Spherical Bearings Size Chart
| BEARING NO. | B | D | W | T | O | M | BALL | a° | STATIC | APPROX | |
| DIA. | DIA. | WIDTH | WIDTH | FLAT DIA. | CHAMFER | DIA. | MIS. | RADIAL | WEIGHT | ||
| +0.0000 | +0.0000 | +0.000 | +0.005 | REF. | REF. | REF. | ANGLE | LOAD | (LBS) | ||
| -0.0005 | -0.0005 | -0.002 | -0.005 | REF. | (LBS) | ||||||
| COM-2(T) | 0.0650 | 0.4687 | 0.250 | 0.187 | 0.235 | 0.020 | 0.343 | 9.0 | 3,200 | 0.010 | |
| COM-3(T) | 0.1900 | 0.5625 | 0.281 | 0.218 | 0.293 | 0.015 | 0.406 | 11.0 | 3,250 | 0.014 | |
| COM-4(T) | 0.2500 | 0.6562 | 0.343 | 0.250 | 0.364 | 0.022 | 0.500 | 13.5 | 4,950 | 0.022 | |
| COM-5(T) | 0.3125 | 0.7500 | 0.375 | 0.281 | 0.419 | 0.032 | 0.562 | 12.0 | 6,475 | 0.030 | |
| COM-6(T) | 0.3750 | 0.8125 | 0.406 | 0.312 | 0.516 | 0.032 | 0.656 | 10.0 | 8,400 | 0.038 | |
| COM-7(T) | 0.4375 | 0.9062 | 0.437 | 0.343 | 0.530 | 0.032 | 0.687 | 8.0 | 9,453 | 0.047 | |
| COM-8(T) | 0.5000 | 1.0000 | 0.500 | 0.390 | 0.640 | 0.032 | 0.781 | 9.5 | 13,250 | 0.065 | |
| COM-9(T) | 0.5625 | 1.0937 | 0.562 | 0.437 | 0.710 | 0.032 | 0.875 | 9.5 | 16,630 | 0.086 | |
| COM-10(T) | 0.6250 | 1.1875 | 0.625 | 0.500 | 0.780 | 0.032 | 0.968 | 8.5 | 21,280 | 0.110 | |
| COM-12(T) | 0.7500 | 1.4375 | 0.750 | 0.593 | 0.920 | 0.044 | 1.187 | 9.0 | 31,920 | 0.204 | |
| COM-14(T) | 0.8750 | 1.5625 | 0.875 | 0.703 | 0.980 | 0.044 | 1.312 | 9.5 | 41,960 | 0.263 | |
| COM-16(T) | 1.0000 | 1.7500 | 1.000 | 0.797 | 1.118 | 0.044 | 1.500 | 10.0 | 55,200 | 0.386 | |
| HCOM-16(T) | 1.0000 | 2.0000 | 1.000 | 0.781 | 1.360 | 0.032 | 1.687 | 9.0 | 70,820 | 0.553 | |
| HCOM-19(T) | 1.1875 | 2.3750 | 1.187 | 0.937 | 1.610 | 0.032 | 2.000 | 8.5 | 100,730 | 0.895 | |
| HCOM-20(T) | 1.2500 | 2.3750 | 1.187 | 0.937 | 1.610 | 0.032 | 2.000 | 8.5 | 100,730 | 0.895 | |
| HCOM-24(T) | 1.5000 | 2.7500 | 1.375 | 1.094 | 1.860 | 0.032 | 2.312 | 8.5 | 135,950 | 1.358 | |
| HCOM-28(T) | 1.7500 | 3.1250 | 1.562 | 1.250 | 2.110 | 0.044 | 2.625 | 8.0 | 176,370 | 1.948 | |
| HCOM-32(T) | 2.0000 | 3.5000 | 1.750 | 1.375 | 2.360 | 0.044 | 2.937 | 8.5 | 217,060 | 2.650 | |
Custom Service Process:Select Similar Product — Confirm MOQ — Send Inquiry — Send your Drawings or Samples — Customization
Select product (If your product is not on our website, select a similar product) — Confirm the quantity you need meet up with our MOQ — Send inquiry with your Drawings or Samples — We will reply to you and confrim details — Send details to our factory and start customization
About Us:
Registration Name: Shanghai YongZhen Machine Components Co., Ltd.
Brand Name: SYZ
Established: 2002
Location: Shanghai,China
Business Type: Manufacturer
Main Products: Rod Ends, Rod Ends Kits, Spherical Bearings, Ball Joints, Linkage Adjuster, Rod Ends Related, Clevis and Yoke, Linkage Suspension, DOM Tubing, Custom Machining
Working Hours: 9:00 AM-18:00 PM Monday to Friday, China Beijing Time GMT+8
Know More About Us, Please Go To About Page or Contact Us.
Packing and Shipping:
Packing: Individual Plastic Bag, Thread with Protected Cover, Exported Carton
Delivery Time: Inventory Parts Shipped at Same Day; Production Usually 30-45 Days
Shipping Method: Air Freight by DHL/TNT /FEDEX Great Discount Rate in 3-7 Days; Headache-Free Ocean Freight with All Procedures Taken Care of to Doorstep in 30-40 Days
