Tube 2"OD Tube Clamp – 2 in Tube Size
OD Tube Clamp Product Overview
OD Tube Clamp – 2 in Tube Size is an outside-diameter tube clamp for chassis structures, removable tube assemblies, roll cage fabrication, and custom structural tubing systems.
The published tube size is 2 in. Additional dimensions can be reviewed from drawings, samples, or special production requirements.
Material references include 4130 chromoly steel or carbon steel, optional black zinc plating, and Grade 10.9 bolt hardware.
OD Tube Clamp Series — Full Size Range
All available sizes in the OD Tube Clamp series. Can’t find your size? Contact us for custom dimensions.
| Type | Part ID | Tube Size / ØA | ØB | Wall Thickness | C (in) | Screw Size |
|---|---|---|---|---|---|---|
| OD Tube Clamp | ODTC-001 | Ø1-1/2" | ||||
| OD Tube Clamp | ODTC-002 | Ø1-3/4" | ||||
| OD Tube Clamp | ODTC-003 | 2" |
Every Unit Inspected Before Shipment
Raw Material Inspection
Material certifications verified. Composition confirmed by spectrometer before machining begins.
Thread Gauge Inspection
100% go/no-go gauge check on all threaded sections. Zero tolerance on dimensional non-conformance.
Load Capacity Test
Static and dynamic load tests run on representative samples from each production batch.
Dimensional Measurement
CMM verification of critical dimensions — ball diameter, bore, thread pitch, and body length.
Surface Inspection
Visual and tactile inspection for burrs, scratches, surface cracks, and plating defects.
Articulation Test
Misalignment angle and torque measured to confirm liner performance meets specification.
Heat Treatment Verify
Hardness tests confirm proper heat treatment on chromoly steel bodies and bearing balls.
Batch Documentation
Full traceability from raw material heat number to finished part. COC and inspection reports available.
Where OD Tube Clamp Are Used
More from the OD Tube Clamp Series
Request a Quote for the OD Tube Clamp Series
Share your part number, required quantity, and any special material or packaging requirements. We respond within 24 hours.
Request a Quote
Please submit the form or email [email protected]
OD Tube Clamp Frequently Asked Questions
What is an OD tube clamp used for?
An OD tube clamp is used around the outside diameter of a tube for mounting, retention, or fabricated assembly support.
Which dimension should I check first?
Start with tube size / ØA, then confirm whether ØB, wall thickness, C dimension, and screw size are required for the project.
How is OD tube clamp selection different from ID tube clamp selection?
OD tube clamps are selected around outside-diameter retention, while ID tube clamps focus on internal/interlocking tube engagement.
Where are OD tube clamps commonly used?
They are used in tube mounting, roll cages, chassis fabrication, custom brackets, removable tube assemblies, and compact fabricated tube systems.
Can the missing dimensions be confirmed before production?
Yes. For OD tube clamp projects, SYZ can confirm additional dimensions from drawings, samples, or special requirements before production.
Can SYZ make custom OD tube clamps?
Yes. Provide tube OD, expected load or use case, drawing, material preference, screw requirement, and quantity for review.
