BALL JOINT LINKAGE

CS Series Threaded Ball Joint Linkage

Name: CS Series Threaded Ball Joint Linkage
Brand: SYZ Rod Ends
Availability: InStock

✓ ISO 9001 Certified

✓ SGS Verified

✓ 26+ Years Factory

✓ OEM / ODM Ready

Thread: Right/Left Regular Size: Inch Size from CSM5-CSM16 Inch Size and Metric Size Both Available Custom Option: Material/Size/Stud

Get a Quote →

⚡ Typically responds within 24 hours

MOQ:50 pcs / model

Lead Time:7–15 days

Sample:Free (excl. freight)

Payment:T/T · PayPal · L/C

Overview

CS Series Threaded Ball Joint Linkage Overview

CS Series Threaded Ball Joint Linkage

Thread:Right/Left
Regular Size: Inch Size from CSM5-CSM16
Inch and Metric Size Both Available
Custom Option:Material/Size

Product Features:
Metric Size, Sealing Cap O20
Ball Stud: Carbon Stell 1045
Clip: Spring Steel
Surface: Silver Zic Plated

PART NO.	THREAD	BALL DIA.	M	C2	C1	D1	D	A	MINICONE	WEIGHT(g)
CSM5	M5 X 0.8	8	M5	10.2	9	10.2	22	8	36°	15.2
CSM6	M6 X 1.0	10	M6	12.5	11	11.5	25	10	36°	25.2
CSM8	M8 X 1.25	13	M8	16.5	13	14	30	13	36°	53.1
CSM10	M10 X 1.5	16	M10	20	16	15.5	35	16	36°	103.8
CSM12	M12 X 1.7	16	M12	20	16	15.5	35	16	36°	105
CSM14	M14 X 1.50	19	M14X1.5	28	20	21.5	45	22	36°	200
CSM14F	M14 X 2.0	19	M14	28	20	21.5	45	22	36°	220
CSM16	M16 X 2.0	19	M16	28	20	21.5	45	22	36°	250

Custom Service Process:Select Similar Product — Confirm MOQ — Send Inquiry — Send your Drawings or Samples — Customization
Select product (If your product is not on our website, select a similar product) — Confirm the quantity you need meet up with our MOQ — Send inquiry with your Drawings or Samples — We will reply to you and confrim details — Send details to our factory and start customization
