ROD END / HEIM JOINT
Glider Bearing Arm Bracket Hardware
Part No.: Glider Bearing Arm Bracket Hardware
· Male & female version available
✓ ISO 9001 Certified
✓ SGS Verified
✓ 26+ Years Factory
✓ OEM / ODM Ready
Right-hand & left-hand thread versions
Male (XM) & female (XF) body types
Misalignment 7°–34° — varies by size
Custom material, finish & OEM packaging
⚡ Typically responds within 24 hours
MOQ:50 pcs / model
Lead Time:7–15 days
Sample:Free (excl. freight)
Payment:T/T · PayPal · L/C
Overview
Rod End Product Overview
Glider Bearing Arm Bracket Hardware
Professional Glider Bearing Arms Manufacturer. Your Reliable Bulk purchasing Partner. Contact Us [email protected] to check the sizes or please tell us which size you need. For More Details, Please Check Our Glider Bearing Arm Page https://syzrodends.com/glider-bearing-arms/.
| Parameter | Imperial (inch) | Metric (mm) |
|---|---|---|
| Overall Length | 7″ / 8″ / 9″ / 10″ / 12″ | 180 / 200 / 230 / 250 / 300 |
| Center Hole Distance | 6″ / 6.5″ / 7.5″ | 152 / 165 / 190 |
| Mounting Hole Diameter | 5/16″ / 3/8″ / 1/2″ | 8 / 10 / 12 |
| Arm Width | 3/4″ / 1″ / 1.25″ | 20 / 25 / 30 |
| Plate Thickness | 1/8″ / 3/16″ | 3 / 4 / 5 |
| Bearing Inner Diameter | 1/4″ / 5/16″ / 3/8″ | 6 / 8 / 10 |
| Bending Angle | 10° / 15° / 20° | Customizable (typically 15°) |
| Bearing Outer Diameter | 7/8″ / 1″ / 1-1/8″ | 22 / 25 / 28 |
| Material Type | Characteristics | Advantages |
|---|---|---|
| Carbon Steel | – High cost-effectiveness – Easy to process – Requires surface treatment (e.g., galvanizing, powder coating) | – Economical pricing – Good strength – Ideal for general-purpose applications |
| Galvanized Carbon Steel | – Zinc coating for rust resistance – Improved corrosion resistance over plain steel | – Extended service life – Suitable for moderately humid environments |
| Powder-Coated Carbon Steel | – Electrostatic powder coating – Protective and decorative finish – Wide color options | – Excellent weather resistance – Corrosion-resistant and durable – Visually appealing |
| Stainless Steel | – Contains chromium for corrosion resistance – High strength – Rust and deformation-resistant | – Superior durability – Long service life in harsh environments |
| Aluminum Alloy | – Lightweight and corrosion-resistant – Easy to machine and form | – Ideal for lightweight applications – No rust, minimal maintenance |
